Official M5Stamp Extend I/O Module (STM32F0)
✓ Paiement protégé✓ Livraison suivie✓ Canadian service

Électronique · H-168120195559

Official M5Stamp Extend I/O Module (STM32F0)

NouveauAvailable from Prime Living

Last unit available

62.99 CAD
Free worldwide shippingEstimated delivery to Canada: 4–10 business days
Product details
SKU
H-168120195559
Product code
H-168120195559
Condition
Neuf
Department
Électronique
Brand
—
Shipping
Free worldwide shipping

COMPLETE INFORMATION

Product description

Product Description

Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)

STAMP IO is an IO expansion board based on STM32F030 main controller, using I2C communication interface, providing 8 IO expansion. Each IO supports independent configuration of digital input/output, ADC, SERVO control, RGB LED control modes. Suitable for multi-channel digital/analog signal acquisition, and lighting/servo control applications.

Product Features

*8-channel input and output expansion.
----Digital input/output
----ADC input
----SERVO control (PWM)
----RGB LED control
----IO pin PWM output function
*I2C communication interface:
----Supports configuration of I2C address
*Multiple soldering options
----Three types soldering options are available (SMT, DIP, Jumper wire),
----With high-temperature resistant plastic enclosure, Peak temperature = 230℃

Included

1x STAMP IO
1x HY2.0-4P female connector (red)
1x Hex key 1.5mm

Applications

IO Expansion
Servo control
Multiple lighting control
Multiple analog signal acquisition

Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)Official M5Stamp Extend I/O Module (STM32F0)
