Product Description
VET Syringe Pump Infusion pump Portable LCD Display Electric Medical Syringe Pump Veterinary Equipment
VET Syringe Pump Infusion pump Portable LCD Display Electric Medical Syringe Pump Veterinary EquipmentIntroductionSH-509iVet Veterinary medical Syringe Pump is an economical product aiming at International users, which can be used in each clinical department and ward, it can control the injection rate and volume featuring in long time, high-accuracy, large range and continuous, and it has fully met the different requirements of modern clinical medical in various occasions.
Features
1)LED & LCD dual display
2)Compact and Ergonomic design with handle for fast transport
3)Users friendly interface for easy operation
4)Drugs library &Wireless monitoring upgradable.
5)Stable injection without pulsation(KVO).
6)Recognize the syringe automatically.
7)Enter KVO state after alarm.
8)Large history data review and last configuration memory to easy review
9)Anti-bolus System to improve infusion safety
10)Super Compatibility with all standard syringes ，The syringes of different brands can be changed as need.
11)The built-in battery provides such functions as auto-switch and auto-charge management under power failure.
12)Various alarm function with volume adjustment lead peace of mind.
13)The disposable syringes of different specifications conformed with national standard can be used, and the accuracy in different injection rate can be controlled by adjusting the parameters.
Performance
Syringe specification: 5 ml, 10 ml, 20 ml,30mland 50/60 ml syringe conformed with national standard
Range of injection rate
5ml:0.1ml/h-150ml/h
10ml:0.1ml/h-300ml/h
20ml:0.1ml/h-600ml/h
30ml:0.1ml/h-900ml/h
50ml:0.1ml/h-1200ml/h
Flow Rate Step:0.1ml/h (0.1-100ml/h Micro Mode)
Flow Rate Accuracy:≤±2% ( including Mechanic Accuracy ±1%)
Volume Limit :0.1-9999.9 ml
Purge Rate :
5ml:150ml/h,
10ml:300ml/h,
20ml:400ml/h,
30ml:600ml/h,
50ml:1200ml/h
Bolus rate :
5ml:10ml/h-150ml/h
10ml:10ml/h-300ml/h;
20ml:10ml/h-400ml/h
30ml:10ml/h-600ml/h;
50ml:10ml/h-1200ml/h
Syringe Modes:Flow Rate, TimeNolume, Drug/Weight, BOLUS
KVO:0.1-5ml/h
Occlusion Alarm :3-level sensitivities setting
Audio & Visual Alarm:Finished, Check Syringe, Drive Disengaged, Pause Overtime, Near Empty ,Empty,
Battery Low, Battery run out, Motor Malfunction, System failure ,Occlusion , AC lost etc.
Drug Library :upgradable
Wireless Monitoring :upgradable
PCA Module:upgradable
History log:Standard
Display:2.8" color TFT
Classification: class I, type CF applied part
Waterproof degree: IP34
Power Source:≤15W, 85V-265V,50Hz/60Hz
Battery :DC12V,2000mAh ( last 7 hours or up at 5ml/hr after fully recharged )
Operation Condition:Temperature: +5C - +40C,Relative Humidity ≤80%,Atmospheric Pressure
70KPa-106Kpa
Dimensions :297mmX 130mmX 108mm
Weight :1.9kg
Working environment:
Temperature: 5 ℃~40 ℃
Atmospheric pressure: 570 hPa~1060 hPa
Relative humidity: 15 %~95 %
No strong vibration and no corrosive gas
Storage environment:
Temperature: -20 ℃~+60 ℃
Atmospheric pressure: 500 hPa~1060 hPa
Relative humidity:10 %~95 %, non-condensing
No corrosive gas
Well ventilation
Package included:
1X SH-509iVET Syringe Pump
1X Power cord
1X User manual
