Product Description
Heltec WiFi LoRa 32 V3 868MHz Development Board Kit Meshtastic ESP32 SX1262 With Case For Arduino IoT LoRaWAN
Heltec WiFi LoRa 32 V3 868MHz Development Board Kit Meshtastic ESP32 SX1262 With Case For Arduino IoT LoRaWANDocs & Resource
Note:
This product does not include batteries!!!
If you need to purchase batteries separately, please select this link:
Specifications
Parameters | Description |
Master Chip | ESP32-S3FN8 (Xtensa®32-bit lx7 dual core processor) |
LoRa Node Chip | SX1262 |
USB to Serial Chip | CP2102 |
Frequency | 470~510MHz, |
Max. TX Power | 21±1dBm |
Max. Receiving sensitivity | -134dBm@SF12 BW=125KHz |
Wi-Fi | 802.11 b/g/n, up to 150Mbps |
Bluetooth | Bluetooth 5 (LE) |
Hardware Resource | 7*ADC1 + 2*ADC2; |
Memory | 384KB ROM; |
Interface | Type-C USB; |
Battery | 3.7V lithium battery power supply and charging |
Operating Temperature | -20 ~ 70 ℃ |
Dimensions | 50.2 * 25.5* 10.2 mm |
