RFT100-250RM2510 Flange type double lead 10/50/75/100Ω 250W high power RF resist

Product Description

Detailed description of 100 ohm 250W RF resistor

Product model: RFT100-250

Rated power: 250W

Nominal resistance value: 100Ω

Resistance tolerance: ±2%

Operating temperature: -55~+150℃

Temperature coefficient: <150ppm/℃

Base material: BeO

Note when using:

1, patch resistance welding devices or leads, it is best to use temperature control sintering table, the temperature is maintained at 260 degrees.

2, PCB board to drill heat dissipation hole, and in the heat dissipation hole really filled with solder.

3. It is best to make an arch bridge shape at the lead (as shown below), which can release the stress generated by thermal deformation, so as to ensure good contact at the lead. During installation, the lead should be broken as little as possible to prevent the lead from breaking.

4. The resistance with flange, the surface in contact with the flange, must be flat, and when the power is particularly large, it is also necessary to coat the thermal conductive silicon for heat dissipation.
