Product Description
Dragino D23-NB-GE NB-IoT Waterproof /Outdoor Temperature Sensor
Dragino D23-NB-GE NB-IoT Waterproof /Outdoor Temperature SensorThe Dragino D23-NB is aNB-IoT Temperature Sensorfor Internet of Things solution. D23-NBwill convert the Temperature reading to upload the sensor data send to IoT platform via NB-IoT network.
The temperature sensor used in D23-NBcan measure -55°C ~ 125°C with accuracy ±0.5°C (max ±2.0 °C).
D23-NBsupportstemperature alarmfeature, user can set temperature alarm for instant notice. D23-NB supportsDatalog feature, it can save the data when there is no NB-IoT network and uplink when network recover.
D23-NBsupports diferent uplink methods includingMQTT, MQTTs, UDP & TCPfor diferent application requirement, and support uplinks to various IoT Servers.
D23-NBsupportsBLE confgure and OTA updatewhich make user easy to use.
D23-NBis powered by8500mAh Li-SOCI2 battery, it is designed for long-term use up to several years.
D23-NBhas optional built-in SIM card and default IoT server connection version. Which makes it works with simple confguration.
Features:
NB-IoT Bands:B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66/B70/B85 @H-FDD
Ultra Low Power Consumption
3 x DS18B20 Temperature probes
Measure range: -55°C ~ 125°C
Temperature alarm
IP66 Waterproof Enclosure
Support BLE remote configure and update firmware
Uplink on periodically
Downlink to change configure
8500mAh Battery for long term use
Nano SIM card slot for NB-IoT SIM
Specifications:
Common DC Characteristics :
Supply Voltage: 2.5v ~ 3.6v
Operating Temperature: -40 ~ 85°C
Temperature Sensor :
Dallas DS18B20
Range: -55 to + 125°C
Accuracy ±0.5°C (max ±2.0 °C).
LoRa Spec :
NB-IoT Module: BC660K-GL
Support Bands:
B1 @H-FDD: 2100MHz
B2 @H-FDD: 1900MHz
B3 @H-FDD: 1800MHz
B4 @H-FDD: 2100MHz
B5 @H-FDD: 860MHz
B8 @H-FDD: 900MHz
B12 @H-FDD: 720MHz
B13 @H-FDD: 740MHz
B17 @H-FDD: 730MHz
B18 @H-FDD: 870MHz
B19 @H-FDD: 870MHz
B20 @H-FDD: 790MHz
B25 @H-FDD: 1900MHz
B28 @H-FDD: 750MHz
B66 @H-FDD: 2000MHz
B70 @H-FDD: 2000MHz
B85 @H-FDD: 700MHz
Battery :
Li/SOCI2 un-chargeable battery
Capacity: 8500mAh
Self-Discharge: <1% / Year @ 25°C
Max continuously current: 130mA
Max boost current: 2A, 1 second
Power Consumption：
STOP Mode: 10uA @ 3.3v
Max transmit power:350mA@3.3v
Package Includes:
1 x D23-NB NB-IoT Temperature Sensor
External antenna x 1
Dimension and weight:
Device Size: 120 * 55 * 200 mm
Device Weight: 372g
Part Number : D23-NB-XX
XX:
GE:General version ( Exclude SIM card)
1D:with 1NCE* 10 years 500MB SIM card and Pre-configure to DataCake server
1NCE SIM Card NB-IoT network coverage:Austria, Belgium, Bulgaria, Croatia, Czech Republic, Denmark, Finland, Germany, Great Britain, Greece, Hungary, Ireland, Italy, Latvia, Malta, Netherlands, Norway, Puerto Rico, Russia, Slovak , Republic, Slovenia, Spain, Sweden, Switzerland, Taiwan, USA, US Virgin Islands
