5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary
✓ Paiement protégé✓ Livraison suivie✓ Canadian service

Automobile · H-168294800229

5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary

NouveauAvailable from Prime Living

12 units available

26.99 CAD
Free worldwide shippingEstimated delivery to Canada: 4–10 business days
Product details
SKU
H-168294800229
Product code
H-168294800229
Condition
Neuf
Department
Automobile
Brand
—
Shipping
Free worldwide shipping

COMPLETE INFORMATION

Product description

Product Description

5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary Lithium/LTO/LiFePO4 balancer5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary Lithium/LTO/LiFePO4 balancer5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary Lithium/LTO/LiFePO4 balancer5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary

Product Overview

The product adopts active balancing technology, using capacitors as carriers to supplement high-energy battery power to low-energy batteries, and energy conversion is carried out within the battery pack to improve the differentiation of battery cells and effectively extend battery life. Its balancing circuit has high efficiency, and the battery charging and discharging process can achieve balancing. The balancing speed is fast, achieving undifferentiated balancing of the entire set. Equipped with sleep function to extend battery life, it can be widely used in various scenarios of series parallel battery pack usage.

Key features

Full-Disk Equalization

Active balancing technology that optimizes energy conversion across the entire battery pack simultaneously.

Achieves voltage balance accuracy up to 5mV, with a minimum balancing voltage difference of 0.01V.
Maximum Balance Current

Can handle a maximum current of 5A when the voltage difference is about 1V, ensuring quick and efficient balancing.

Automatic Low-Voltage Sleep

Stops working and enters sleep mode when the battery voltage falls below 2.7V, protecting the battery from over-discharge.

5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary

Technical Specifications

Applicable Battery Type: NCM/LFP/LTO

Voltage Range:1.8V to 4.2V (for NCM/LFP batteries)

Balance Voltage Accuracy: 5mV (typical)

Maximum Balancing Current: 5A (when voltage difference is around 1V)

Minimum Balance Voltage Difference: 0.01V

Static Operating Current: 13mA

Undervoltage Protection (Sleep Mode): 2.7V

Operating Temperature Range: -10°C to 60°C

External Power Supply: Not required (powered by the internal battery energy)

Single String Voltage Range: 2V to 5V

Measurement Accuracy: 0.5% or ±5mV

5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary5A battery cell balance module 4s 3S 5S 6S 7S 8S 12S 13S 16S 20S 21S for Ternary
