Heltec lifepo4 bms 24v 6s bms 7s8s 10S li ion balanced 18650 30A 50A 60A 80A lit

Product Description

6S/7S/10S 30A 3.7V Same Port

Size：63×48×8
Overcharge protection : 4.25v
Over-discharge protection : 2.8v
Abnormal high voltage protection
Temperature protection optional
Maximum continuous current : 30A
Discharge over current protection : 100A
Load short circuit protection
Balance current : 83 mA
Charging recovery

8S 3.2V 30A Same port

8S Lifepo4 30A:
DIMENSIONS: 63*48MM
Specification: 8S Lifepo4 30A
Overcharge: 3.65V±0.025
Charge recovery: 3.55V±0.025
Over discharge: 2.3V±0.025V
Discharge Recovery 2.5V±0.025V.
Balance: 3.45±0.025V
Current: 25A, if do good cooling can 30A.
Withstands transient peak current: 150A
Application: Nominal 3.2V lifepo4 iron phosphate battery
Operating temperature: -30/+80°С
Self-consumption: <35uA
The product application range is mainly used for motor or energy storage products within 12V 500W.

6S/7S/10S 60A 3.7V Same Port

Size: 63×48×14
Overcharge protection : 4.25v
Over-discharge protection : 2.8v
Abnormal high voltage protection
Temperature protection optional
Maximum continuous current : 60A
Discharge over current protection : 200A
Load short circuit protection
Balance current : 83 mA
Charging recovery
Application：
Applicable to 24V Electric bicycle and electric tools within 1200W

8S 3.2V 60A Same port

8S Lifepo4 60A:
DIMENSIONS: 63*48MM
Specification: 8S Lifepo4 60A
Overcharge: 3.65V±0.025
Charge recovery: 3.55V±0.025
Over discharge: 2.3V±0.025V
Discharge Recovery 2.5V±0.025V.
Balance: 3.45±0.025V
Current: 50A, if do good cooling can 60A.
Withstands transient peak current: 300A
Application: Nominal 3.2V lifepo4 iron phosphate battery
Operating temperature: -30/+80°С
Self-consumption: <35uA
The product application range is mainly used for motor or energy storage products within 12V 1000W.

6S/7S 3.7V 80A Same Port

Size: 72*55*8mm
Overcharge protection: 4.25v±0.25v
Charging recovery: 4.2V±0.25v
Over-discharge protection: 2.8v±0.25v
Discharge recovery: 3.0v±0.25v
Maximum continuous current: 80A
Peak Current: 240A
Balance current: 80 mA
Balanced starting voltage: 4.22v±0.25v
Charging recovery
Self-consumption: ≤35uA

8S 3.2V 80A Same Port

Size: 72*55*8mm
Overcharge protection: 3.65v±0.25v
Charging recovery: 3.55V±0.25v
Over-discharge protection: 2.35v±0.25v
Discharge recovery: 2.55v±0.25v
Maximum continuous current: 80A
Peak Current: 240A
Balance current: 80 mA
Balanced starting voltage: 3.405v±0.25v
Charging recovery
Self-consumption: ≤35uA
