TE5000 Miniature Differential Pressure Gauge 53mm 0-500Pa 0-5kPa HVAC Air Filter

Product Description

Air Differential Pressure Gauge TE5000 (0-250Pa) - Compact, Easy to Install, High Precision

Available Measurement Ranges:
0-125Pa, 0-250Pa, 0-300Pa, 0-500Pa, 0-750Pa, 0-1KPa, 0-1.5KPa, 0-2KPa, 0-2.5KPa, 0-3KPa, 0-5KPa, 0-10KPa
Custom non-standard ranges are available upon request.

Ordering Notice:
Please specify your required measurement range when placing an order.

Product Description:
The TE5000 Air Differential Pressure Gauge is designed for precise measurement of low-pressure differentials. It is widely used for monitoring fan and blower pressure, filter resistance, airflow velocity, furnace pressure, orifice differential pressure, water levels, and hydraulic system pressure. It is also suitable for process gas measurement, combustion air ratio control, automatic valve regulation, and medical equipment such as blood pressure and respiratory pressure monitoring.

Specifications:

• Model: TE5000

• Measurement Range: 0-250Pa (optional)

• Rated Operating Pressure: -68 ~ 103KPa

• Material: Reinforced filled nylon housing, polycarbonate lens

• Interface: 3/16 inch standard barb for direct pipe connection; optional 1/8 inch interface for temperature and pressure

• Accuracy: ±5% of full scale at 70°F (21.1°C)

Key Features:

1. Frictionless gear-free design for smoother pointer movement

2. No internal liquid fill, ensuring no inertia or pointer drift

3. Excellent vibration and shock resistance

4. Capable of measuring positive, negative, or differential pressure with strong overload protection

5. Flexible installation options for various applications

6. Compact structure with low power consumption and high precision

7. Durable reinforced nylon housing with impact-resistant polycarbonate lens

8. Overpressure protection with explosion-proof diaphragm and membrane

Important Notes:

1. Product images are for reference only; slight differences do not affect functionality.

2. Colors may vary slightly due to monitor differences.

Package Includes:
1 x TE5000 Air Differential Pressure GaugeQ: Can the TE5000 Air Differential Pressure Gauge measure both positive and negative pressures?
A: Yes, the TE5000 is designed to measure positive, negative, and differential pressures, making it ideal for a variety of applications.
