WP8024ADAM 8DI 4RO PLC Digital input Relay output module Optocoupler isolated RS

Product Description

1,Product description

Eight optoelectronic isolation digital input channel (Low level input)

Four relay output channel (SPST)

RS485 MODBUS RTU standard communication protocol

Netted with configuration software, PLC or industry touch panel

Communication, digital input and digital output status LED

Communication circuit designed for thunder protection and interference immunity

Used for signal collection and control in industrial field

2,Specification

Digital input channel 8ch (Low level input)

Relay output channel 4ch (SPST)

Relay contact capacity 2A/250VAC 2A/30VDC

Working temperature -20~70℃

External power supply DC9V~30V/5W

Isolation protection DC1500V

Installation method Standard DIN slide rail or screw

Dimension 125×73×35mm
