Product Description
Professional 1408 Channels Imu Gnss Rtk Ihand55 Collector Hi-Survey Software V300 V500 Gnss
Professional 1408 Channels Imu Gnss Rtk Ihand55 Collector Hi-Survey Software V300 V500 GnssProduct DescriptionProfessional 1408 Channels Imu Hi Target Gnss Rtk Ihand55 Collector Hi-Survey Software Hi Target V300 V500 Gnss
Specification| 1408 Channels IMU Tilt Survey GNSS Receiver Hi-Target V300 Gnss Rtk With Camera | ||
GNSS Configuration | Number of channels | 1408 |
| BDS | B1I，B2I，B3I，B1C，B2a，B2b | |
| GPS | L1C/A，L1C，L2P(Y)，L2C，L5 | |
| GLONASS | L1，L2 | |
| GALILEO | E1，E5a，E5b | |
| GALILEO | E1，E5a，E5b，E6* | |
| QZSS | L1，L2，L5，L6* | |
| IRNSS | L5* | |
| SBAS | L1，L2，L5 | |
| L-BAND* | YES | |
| Output format | ASCII: NMEA-0183, binary code | |
| Positioning output frequency | 1Hz~20Hz | |
| Differential support | CMR、RTCM2.X、RTCM3.0、RTCM3.2 | |
| Static format support | GNS, Rinex dual format static data | |
| Differential format | RTCM2.X, RTCM3.X | |
| Network mode | VRS, FKP, support NTRIP protocol | |
System Configuration | Operating system | Linux operating system |
| Data storage | Built-in 16GB ROM, supports automatic cycle storage of static data | |
Precision and Reliability | RTK positioning accuracy | Plane: ±(8+1×10-6D) mm |
| Elevation: ±(15+1×10-6D) mm | ||
| Static positioning accuracy | Plane: ±(2.5+0.5×10-6D) mm | |
| Elevation: ±(5+0.5×10-6D) mm | ||
| DGPS positioning accuracy | Plane accuracy: ±0.25m+1ppm; | |
| Elevation accuracy: ±0.50m+1ppm | ||
| SBAS positioning accuracy | 0.5m | |
| Tilt measurement accuracy | 8mm+0.7mm/°tilt | |
| Visiual stakeout accuracy | 1cm | |
| Initialization time | <10 seconds | |
| Initialization reliability | ＞99.99% | |
| RTK keep technology | YES | |
Camera | Function | Professional star-level night vision high-definition camera, super large viewing angle, support live-view stakeout |
Communication | Cellular mobile | Built-in 4G network communication: TDD-LTE, FDD-LTE, WCDMA, TD-SCDMA, EDGE，GPRS，GSM |
| I/O Interface | USB type C interface; SMA interface | |
| WiFi | 802.11b/g access point and client mode, can provide WiFi hotspot service | |
| Bluetooth | Bluetooth® 2.4GHz, BT5.2 | |
| NFC | Support NFC IGRS | |
| Power | 1W/2W/5W adjustable | |
| /TK internal UHF radio | 0.5W/1W/2W adjustable 410MHz~470MHz | |
| HI-TARGET，TRIMTALK450S，TRIMMARKⅢ, TRANSEOT，SOUTH，CHC，SATEL | ||
| 116 frequency bands adjustable | ||
Sensor | Electronic Bubbles | Realize Smart Alignment |
| Tilt measurement | IMU | |
User Interface | Panel | Single button |
| Indicator light | Satellite lights, signal lights, power lights | |
Electrical physical properties | battery | High capacity lithium battery 6800mAh, working time is more than 16 hours |
| Input voltage | USB 15W charger | |
| size | Φ158mm×98mm | |
| weight | ≤1.2kg (including battery) | |
Environmental characteristics | Dust and water release | IP68 |
| Anti-fall | Resistance to natural drop of 2 meters | |
| Operating temperature | -40℃~75℃ | |
| Storage temperature | -55℃~+85℃ |
