Rk9920 /RK9910 program controlled insulation and withstand voltage tester AC:0.0

Product Description

Rk9920 /RK9910 program controlled insulation and withstand voltage tester AC:0.05-5.00kv DC:0.05-6.00kv

product description
This series of program-controlled withstand voltage testers are high-performance safety testers designed with high-speed MCU and large-scale digital circuits. The size of the output voltage, the rise and fall of the output voltage. The frequency of the output voltage is safely controlled by MCU, which can display the breakdown current and voltage value in real time, and has software calibration function. It is equipped with PLC interface, RS232C, RS485, USB device, and USB Host interface, which can easily form a comprehensive test system with a computer or PLC. . It can quickly and accurately conduct comprehensive safety measurement of household appliances, instruments, lighting appliances, electric heating appliances, computers, and information equipment.
This instrument complies with IEC60335-1, GB4706.1, UL60335-1 Safety of Household and Similar Electrical Appliances Part 1: General Requirements Safety requirements for electrical equipment, video and similar electronic equipment IEC61010-1, GB4793.1 Safety requirements for electrical equipment for measurement, control and laboratory use Part 1: General requirements

Application field

Components: diodes, triodes, high-voltage silicon stacks, various electronic transformers, connectors, high-voltage electrical appliances
Household appliances: TVs, refrigerators, air conditioners, washing machines, dehumidifiers, electric blankets, chargers, etc.
Insulation materials: heat shrinkable sleeves, capacitor films, high voltage sleeves, insulating paper, insulating shoes, insulating rubber gloves, PCB circuit boards, etc.
Instrumentation: oscilloscope, signal generator, DC power supply, switching power supply, etc.
Lighting appliances: ballasts, road lights, stage lights, portable lamps and other lamps
Electric heating appliances: electric drill, pistol drill, gas cutter, grinder, grinder, electric welding machine, etc.
Wire and cable: high voltage wire, off cable, cable, silicone rubber cable, etc

Performance characteristics
1. The AC/DC withstand voltage function adopts DDS digital signal synthesis technology to generate accurate, stable, pure and low-distortion waveforms
2. Adjustable high voltage rise and fall time, adapt to different test objects, require arc detection function, test results can be saved synchronously
3. With dual-frequency comprehensive test, frequency range 50Hz, 60Hz, user-friendly operation interface, support digital key input, dial input, more concise operation
4. Complete operation help prompts, which can effectively improve user efficiency, support character file name input, and the maximum length of the file name is 12 characters
5. Simultaneous display of test steps and system status information, which is convenient for understanding the details of test steps and system status during testing
