Product Description
Concrete Compression Strength Testing Machine
Concrete Compression Strength Testing Machine2000KN cement block compression testing machine compressive test equipment for concrete and brick Product Details
Product Application
1. DYE-2000 electro-hydraulic pressure testing machine is driven by hydraulic power source, and intelligent measurement and control instrument is used to collect and process test data. It is composed of four parts: test host, oil source (hydraulic power source), measurement and control system and test apparatus. The maximum test force is 1000kN, and the accuracy level of the testing machine is better than level 1.2. DYE-2000 electro-hydraulic pressure testing machine can meet the national standard test requirements for brick, concrete, cement and other materials. Manual loading and digital display of loading force value and loading speed value.
3. The testing machine is the main engine oil source integrated structure;It is suitable for compressive test of cement and concrete. With appropriate fixture and measuring device, it can meet splitting test, bending test and static compressive elastic modulus test of concrete.
| Model | DYE-2000A |
| Name | Manual screw digital display compression testing machine |
| Maximum test force (KN) | 2000 |
| Test accuracy | Level 1 |
| Space adjustment method | Manual screw adjustment |
| Piston stroke | 0-50 |
| Press space(mm) | 320 |
| Sensor type | Oil pressure |
| Upper platen size (mm) | 240x240 |
| Lower platen size (mm) | 240x240 |
| Motor powder (KW) | 0.75 |
| Mainframe dimensions(mm) | 900x400x1250 |
| Machine weight(kg) | 600 |
Company information The Foreign Trade Department of Cangzhou Lovely Group Co.,Ltd. was established.According to customers' requirements, there has the machine---CZY5 Rebar Weighing and Length Measuring InstrumentIndependent research and development and production of GW50 Automatic Rebar Bending Testing Machine.L800 Integrated Floor Thickness Gauge RBL+ Rebar Detector goes public.New product-- U900 Series Non-Metallic Ultrasonic Detector.
HYE-2000 Series Microcomputer Servo Compression Testing Machine: Pad adjustment, Manual screw adjustment, Electric screw adjustment.WAW-B Micro Electromechanical Liquid Servo Universal Testing Machine.EV2 Static Deformation ModulusTester; EVD Dynamic Deformation Modulus Tester. ---Patented ProductThe factory was established, begin to produce more than 20 types instrument. Our Services Pre-sale service
After-sales service
Packing & Delivery
