Product Description
LNMD-56H Intelligent Carbon Dioxide Density Relay Calibrator High-precision High Accuracy Portable Aluminum Alloy Gas
LNMD-56H Intelligent Carbon Dioxide Density Relay Calibrator High-precision High Accuracy Portable Aluminum Alloy Gas
1. High testing accuracy: The core components adopt imported devices, with high integration, precision, repeatability, and reliability. 2. Highly intelligent: The calibration process does not require a constant temperature chamber, and SF6 gas density relays and pressure gauges can be calibrated within any effective temperature range. Using pressure and temperature dynamic compensation algorithms, automatically complete pressure measurement and conversion of equivalent pressure values at 20 ° C, and display the current temperature pressure and equivalent pressure at 20 ° C, effectively solving the problem of difficult on-site calibration of SF6 gas density relays. 3. Powerful function: capable of simultaneously testing one set of alarm signals and two sets of locking signals, and has the function of verifying normal temperature pressure gauges and 20 degree pressure gauges. 4. Friendly human-machine interface: Equipped with a large Chinese LCD screen and a rotating mouse, the human-machine interface is easy to operate, beautiful, and all parameters and states are clear at a glance. The testing process is automatically completed by the instrument, without the need for manual intervention, avoiding tedious manual air path adjustment operations. 5. All supporting transition joints: The SF6 gas density relay calibrator is equipped with various types of transition joints for portable instruments. Most types of switch density relays can be calibrated on site without disassembly, making it a high-quality choice for SF6 density relay calibration. 6. Low gas consumption: During the calibration process, the gas consumption is minimal, SF6 gas is not wasted, the testing cost is low, and there is no pollution.7. Support for data storage: The instrument has built-in memory, which can instantly save test results. It has the function of saving power down data, and can query and print historical test data at any time. 8. Support report printing: Print test results in Chinese character report format and intelligently analyze the test results. 9. Clock modification: With the function of modifying the system clock online 10. USB flash drive transfer: supports USB flash drive transfer test data, which can be read from a PC, making the operation simple and fast 11. PC software is powerful: PC application software is powerful and easy to operate, enabling data analysis, saving, printing, and generating complete test reports, making it easy for centralized data management.
| Working Power Supply | AC 220V、50HZ |
| Instrument Power | 50W |
| Instrument Accuracy | 0.2 Level |
| Pressure Calibration Range | 0~1MPA |
| Pressure Calibration Resolution | 0.001MPA |
| Temperature Measurement Range | -20°C~80°C |
| Temperature Measurement Resolution | 0.1° |
| Working Humidity | ≤90%RH |
| Verification Object | Single alarm, single lock, single alarm, single lock, single alarm, double lock |
| Sf6 Gas Density Display Method | Pressure in the tested environment, equivalent pressure at 20 ° C |
| Display Method | 320x240 LCD screen |
| Operation Mode | Rotate the mouse (one click shuttle) input |
| Display Method | 320x240 LCD screen |
| Printer Type | High speed micro printer |
| Printing Method | Chinese/English character report printing |
| Storage Capacity | Simultaneously storing 150 sets of test results |
| Overall Dimensions | Host: 400x320x160 (MM3); Weight: 6.2KG； Accessory box: 400x370x200 (MM3); Weight: 4.8KG |
