EVERFINE PF9811 power consumption of electrical parameters harmonic analysis tes
✓ Paiement protégé✓ Livraison suivie✓ Canadian service

Maison · H-168152441987

EVERFINE PF9811 power consumption of electrical parameters harmonic analysis tes

NouveauAvailable from Prime Living

Last unit available

1746.99 CAD
Free worldwide shippingEstimated delivery to Canada: 4–10 business days
Product details
SKU
H-168152441987
Product code
H-168152441987
Condition
Neuf
Department
Maison
Brand
—
Shipping
Free worldwide shipping

COMPLETE INFORMATION

Product description

Product Description

EVERFINE PF9811 power consumption of electrical parameters harmonic analysis tester digital power meter 3.0V～600V 5mA～20AEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tester digital power meter 3.0V～600V 5mA～20AEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tester digital power meter 3.0V～600V 5mA～20A

EVERFINE PF9811 power consumption of electrical parameters harmonic analysis tester digital power meter 3.0V～600V 5mA～20A


In addition to the basic electrical parameter measurement function, pf9811 also has the harmonic analysis function. The instrument adopts PLL method, which can accurately calculate the total harmonic distortion (THD) and each harmonic value of voltage and current. Equipped with special test software, users can observe, print and store the actual voltage and current waveform, spectrum diagram and test data through the computer. It is a powerful helper for harmonic measurement.



Model


PF9810


PF9811


4 displays


V, A, W, PF/ Hz/THD/CF


Voltage


3.0V~600V


3.0V~600V


Current


0.5mA~2000mA


5mA~20A


Range switch


Auto


PF


-1.000~+1.000


Frequency


AC:45Hz~65 Hz, Band 5kHz


Accuracy


(0.4%reading+0.1%range+1digit)

Harmonic analysis


Measure the THD and 2nd~50th sub-harmonic of Voltage and Current


Communication


RS-232, RS485 interface (optional)


Holding function


Easy to read

EVERFINE PF9811 power consumption of electrical parameters harmonic analysis tesEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tesEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tesEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tesEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tesEVERFINE PF9811 power consumption of electrical parameters harmonic analysis tes
