Product Description
Secondary Current Injection Relay for Set 3 Phase Handheld Relay Protection Tester High Accuracy IP55 Protection 0.5%
Secondary Current Injection Relay for Set 3 Phase Handheld Relay Protection Tester High Accuracy IP55 Protection 0.5%Huazheng Secondary Current Injection Relay Test Set 3 Phase Handheld Relay Protection Tester With High Accuracy
Product DescriptionTest Function
Manual Test:The manual test can output three AC voltages and three AC currents, and the amplitude, phase, frequency and sequence component of the AC quantity can be controlled manually by step size.
State Sequence Test:Status can be carried out action time test, multi-state simulation of failure, up to 5 states can be set, can be simulated after re-closing acceleration, can also be combined with the company's wechat analog circuit breaker for backup self-firing test.
Low Cycle Load Shedding Test: The unit can perform fixed point test for low cycle load shedding action value, action time, slip lock value, voltage lock value, current lock value.
Concurrent Test: The unit can test the relevant indicators of the test concurrent device
Harmonic Unit: The unit can be used for the second harmonic inrush current blocking test of transformer differential protection.
Cross Sampling Test: This unit is mainly used to measure the sampling accuracy of the AC sampling device.
Remote Test: The unit can quickly open two pairs of nodes, the intermediate interval time can be freely set, the minimum resolution of 1ms.
Millisecond Meter: The unit can cooperate with the scene to do some open quantity, flip timing.
The specific functions are described as follows:
Manual test functions | Can arbitrarily set the AC amount of various voltages, current amplitude, phase, and set various fault types of parameters |
Test the electrical performance of relays and protection with AC voltage (including phase voltage, line voltage, sequence voltage, positive sequence voltage, negative sequence voltage), AC current (including phase current, line current,) amplitude, phase, frequency, impedance and other variables. | |
The step size can be manually controlled, and the step size can be changed by any setting variable | |
Changes in output can be controlled | |
Monitor changes in the input volume | |
Action time can be tested | |
Multiple continuous state tests | Provides a variety of state sequence settings |
Provide a variety of time control, input control, manual trigger for state switching | |
Can set various types of faults, including single grounding, two-grounding, interphase short circuit, three-phase short circuit. Fault type Instantaneous fault, permanent fault, transformational fault, and can control the fault transition time | |
Can provide constant current, constant impedance and other test methods | |
It can simulate the opening and closing time of the short-circuit device | |
Can provide a separate voltage output as sequence voltage or line extraction voltage As sequence voltage can be set to ±3U0 or ±3√3U0; The amplitude and phase of the voltage can be set at will when the line extraction voltage is tested | |
Can check the opening, opening and logical relationship of the action behavior of relays, protection and safety automatic devices | |
The amplitude and phase of voltage and current can be set arbitrarily | |
Can set the status parameters of various faults | |
Can control each switching quantity separately | |
Dedicated test function | Low cycle load shedding |
Concurrent test | |
Harmonic test | |
AC sampling test | |
Millisecond timing function | |
Remote test |
ABOUT US
Huazheng, established in 2008, is a enterprise which is engaged in the research, development,
sale and service of transformer tester, transformer oil tester, relay tester, high voltage tester, circuit breaker tester. We are a cooperative supplier of the State Grid of China, and we have also
established cooperative relationships with customers in countries and regions such as USA, Brazil, Chile, Vietnam, Indonesia, Korea, Turkey, Dubai, South Africa, etc.We have obtained ISO and
CE certificates. And developed impeccable inspection organization to make sure all of our
products quality comply with international standards(like IEC/ASTM/EN).
