Product Description
CH2904A Digital Power Meter Four channel
CH2904A Digital Power Meter Four channelCH2904A Digital Power Meter Four channel
Feature:
■ High Definition 4.3 inch TFT color display, display the data in all channels
■ Simultaneous test in dual-channel or four channel, improve the production efficiency
■ Min. test current 0.05 mA，power 0.001W，for micro power test like standby power consumption
■ All test value is Trms
■ Auto range, accuracy: 0.5 classes
■ Simple and fast setting for high and low limit warning function, support data lock
■ Super anti interference ability
■ Standard RS232C and USB Device communication interface
■Standard rack size, adopting soft rubber material in front and rear panel, beautiful and anti-skidding
Specification：
CH2902 | CH2904 | CH2902A | CH2904A | |
Wiring | Single phase | |||
Input channel | Dual | Four | Dual | Four |
Display | 4.3 inch TFT color screen | |||
Parameter | Voltage V, current A, power W, power factor PF, frequency Hz, electrical energy | |||
Test mode | Trms | |||
Voltage range | 5-600V AC (range auto switch)，peak voltage:700V AC Min. test voltage 5V AC 分resolution 0.1V | |||
Voltage input mode | AC | AC | ||
Current range | 10mA-20A AC(range auto switch)，peak current :26A AC， Min. Test current 10mA AC | 0.05mA-20A AC(range auto switch)，peak current :6.5A AC， Min. Test current 0.05mA AC | ||
Current input mode | AC | |||
Power range | 0.1W-12kW | 0.001W-3000W | ||
Power factor range | 0.001-1.000 Formula: W÷[ (V)× (A)]= (PF) | |||
Frequency range | 45-65Hz | |||
Test accuracy | ±0.4% reading+0.1 % range | |||
Test speed | 5 times/s | |||
Input impedance | ≥1MΩ(All voltage bins) | |||
Interface | RS-232C，USB Device | |||
Data save | USB HOST | |||
Limit alarm | Yes | |||
WIFI router | Optional | |||
Input voltage range | 110V/220V AC, 50/60 Hz |
