High precision Automatic Industrial 6 Axis Collaborative Robot Cobot 3Kg 5Kg 10Kg Payload Robotic Arm for Palletizing WeldingName
Intelligent Collaborative Robot
Specification
Model
CFR5-922
Payload
5kg
Reach
922mm
Degrees of freedom
6 rotating joints
HMI
10.1 inch teach pendant or mobile terminal Web APP
Movement
Repeatability
±0.02mm
Pose repeatability oer ISO 9283
±0.02mm
Axis movement
Working range
Maximum speed
1 axis
±175°
±180°/s
2 axis
﹢85°/﹣265°
±180°/s
3 axis
±160°
±180°
4 axis
﹢85°/﹣265°
±180°/s
5 axis
±175°
±180°/s
6 axis
±175°
±180°/s
Typical TCP speed
1m/s
Features
IP classification
IP54(IP65 Optional)
Noise
＜65db
Robot mounting
Any orientation
I/O Ports
digital input (DI) 2 digital output (DO) 2 analog input(AI) 2 analog ouput(AO) 2 High speed pulse input 2
Tool I/O power supply
24V/1.5A
Physical
Footprint
149 mm
Weight
≈22kg(Weight without wire)
Operating temperature
0-45℃
Operating humidity
90%RH(non-condensing)
Materials
Aluminium、Steel
Average Power
260W
Control Box
Standard communication
I/O、TCP/IP、Modbus_TCP/RTU
Optional communication
CC-Link、 Profinet、 Ethernet/lP、 EtherCAT
Softwaredevelopmentkit
C#/C++/Python/ROS/ROS2
L*W*H
245*180*44.5mm
Weight
2.1kg
Materials
Galvanized plate
Power supply
30-60VDC
Machine Language
English, Chinese, Russian, Korean, Japanese, French, etc. Customization supported.
