Product Description
BX-500 0.95 Target Emissivity Portable IR Temperature Calibrator 50ºC ~ 500ºC/ 122ºF ~ 932ºF 40 min Heating 45 40 min Cooling
BX-500 0.95 Target Emissivity Portable IR Temperature Calibrator 50ºC ~ 500ºC/ 122ºF ~ 932ºF 40 min Heating 45 40 min CoolingPlease contact us to get bottom price!
Portable IR Calibrators
BX-350/BX-500 portable IR calibrators are used for calibrating long distance Infrared Thermometer, which are designed as handhold and small calibrators.
Easily certify IR pyrometers to 500°C/932°F (BX-500)
Large 2.25" (57 mm) blackbody target
RTD (Resistance Thermometer detector) reference well for high precision
Whether you're using in-line or handheld infrared pyrometers, you need a high performance calibration standard to verify accuracy. Portable IR Calibrator provides a stable lackbody target for calibrating non-contact IR thermometers up to 500ºC (BX-500).
Size(HxWxD): 180mm x 114mm x 233mm
Weight: 2682g
Specifications | BX-350 | BX-500 |
Temperature Range | 50ºC ~ 350ºC/ 122ºF ~ 662ºF | 50ºC ~ 500ºC/ 122ºF ~ 932ºF |
Accuracy | ±0.5ºC @ 100ºC/ ±1.0ºF @ 212ºF ±1.2ºC @ 350ºC/ ±2.4ºF @ 662ºF | ±0.5ºC @ 100ºC/ ±1.0ºF @ 212ºF ±1.8ºC @ 500ºC/ ±3.6ºF @ 932ºF |
Stability | ±0.1ºC @ 100ºC/ ±0.2ºF @ 212ºF ±0.2ºC @ 350ºC/ ±0.4ºF @ 662ºF | ±0.1ºC @ 100ºC/ ±0.2ºF @ 212ºF ±0.3ºC @ 500ºC/ ±0.6ºF @ 932ºF |
Target size | 2.25" (57mm) | 2.25" (57mm) |
Target Emissivity | 0.95 | 0.95 |
Resolution | 0.1ºC/ºF | 0.1ºC/ºF |
Heating Time | 30 minutes to max | 40 minutes to max |
Cooling Time | 30 minutes max to 100ºC | 45 minutes max to 100ºC |
Power | 230 VAC (±10%), 1.5 A; or 110V AC, 3A |
Whether you're using in-line or handheld infrared pyrometers, you need a high performance calibrationstandard to verify accuracy. Portable IR Calibrator provides a stable blackbody target for calibrating non-contact IR thermometers up to 500ºC (BX-500).
The portable IR calibrator features a large temperature controlled blackbody target with a diameter of 2.25" (57 mm), which offers a wide field of view area for optical variations in IR thermometers. With an emissivity of 0.95, the isothermal target can be controlled in set-point increments of 0.1° from 50ºC to 500ºC (BX-500).
For even higher precision, a contact calibration well is located directly behind the blackbody surface.Using an optional digital RTD thermometer and calibrated secondary probe, accuracies of ±0.1ºC canbe achieved.
