OW18B Digital Smart Multimeter 6000 Counts Bluetooth Multimeter True RMS 1000V AC DC Voltage Tester Ammeter Frequency Meter
OW18B Digital Smart Multimeter 6000 Counts Bluetooth Multimeter True RMS 1000V AC DC Voltage Tester Ammeter Frequency MeterOW18B Bluetooth Digital MultimeterOW18B digital multimeters provide True-RMS measurement, 5999-count resolution, non-contact voltage detection and many convenient features for users’ testing needs. These auto-ranged meters can measure up to 1000V DC 750V AC voltage, 20A AC/DC current and 60MΩ resistance. The easy-to-use interface with backlight enables you to detect equipment quickly even in dark places.
1. Large display with flashlight
Large display with high brightness flashlight. Can implement the test among darkness.
2. NCV non-contact voltage sense
While getting the non-contact voltage sensor close to conductor, the instrument will beeps and flash with the frequency according to AC voltage strength.
3. Functioning as multimeter + datalogger
the measured data always updated, and auto- recorded to mobile device, saving labor to do on-site records;
the recoding duration, and sampling duration could be customized, accessible in chart mode, facilitating comparison
analysis between several multimeters.
4. Offline recording function - your process analyzer
possible to record data into memory, but no need to leave mobile device on-site when data-processing, use mobile device to recall the saved data offline data-recording could continue for max 7 days (168 hours).
5. Data- saving, recalling, and comparatively analyzing
CSV format data export supported, the history data could be recalled for comparison analysis;
with the assistance of chart mode, the measured result more visualized, easier for decision- making.
＋Performance Specifications
Measurement Range | Resolution | Accruacy | ||
DC Voltage | 60.00mV / 600.0mV (EU) | 0.01 mV | ±(0.5%+2 dig) | |
600.0mV / 6.000V / 60.00V / 600.0V | 0.1 mV | |||
1000V | 1 V | ±(0.8%+2 dig) | ||
AC Voltage | 6.000V / 60.00V / 600.0V | 1 mV | ±(0.8%+3dig) | |
750V | 1 V | ±(1%+3dig) | ||
DC Current | μA | 600.0μA / 6000μA | 0.1μA | ±(0.8%+2dig) |
mA | 60.00mA / 600.0mA | 0.01mA | ||
A | 20.00A | 0.01A | ±(1.2%+3dig) | |
AC Current | μA | 600.0μA / 6000μA | 0.1μA | ±(1%+3dig) |
mA | 60.00mA / 600.0mA | 0.01mA | ||
A | 20.00A | 0.01A | ±(1.5%+3dig) | |
Resistance | 600.0Ω / 6.000kΩ / 60.00kΩ / 600.0kΩ / 6.000MΩ | 0.1Ω | ±(0.8%+2dig) | |
60.00MΩ | 0.01 MΩ | ±(2%+3dig) | ||
Capacitance | 60.00nF / 600.0nF / 6.000μF / 60.00μF | 0.01nF | ±(3%+3dig) | |
600.0μF / 6.000mF / 60.00mF | 0.1μF | ±(3%+5dig) | ||
Frequency | 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz | 0.001Hz | ±(0.8%+2dig) | |
Duty Ratio | 0.1% - 99.9% ( typical value：Vrms=1V, f=1kHz) | 0.1% | ±(1.2%+3dig) | |
0.1% - 99.9% ( ≥1kHz ) | ±(2.5%+3dig) | |||
Temperature (°C/°F) | - 50 ℃~ +400℃ | 1℃ | ±(2.5%+3dig) | |
-58 ℉~ +752 ℉ | 1℉ | ±(4.5%+5dig) | ||
Display | 5999 | |||
Frequency Response | (40 - 1000) Hz | |||
Shift Rate | 3 times/s |
Bluetooth Module | √ (only in OW18B) | Auto Ranging | √ |
True RMS | √ | LCD Backlight | √ |
Diode Test | √ | Automatic-manual Range Selection | √ |
Auto Power-off | √ | Input Protection | √ |
On-off Warning | √ | Input Impedance | ≥10MΩ |
Low-battery Indicator | √ | Safety Compliance | 600V CATⅣ, 1000V CATⅢ |
Data Hold | √ | NCV | √ |
Relative Measurement | √ | Dimension (W×H×D) | 190 x 90 x56 (mm) |
Flashlight | √ - | Weight (without package) | 0.32 kg |
＋
electronic circuit debugging circuit testing design and manufacture
education and training automobile maintenance and testing
＋The accessories subject to final delivery.
Multimeter K-type Manual Alligator Clip Alligator Clip
Lead Thermocouple （optional） (optional)
