OSD OLED Display for Pixhawk 2.4.8 PIX PX4 Flight Control Flight display flight

Product Description

Use OLED for PIXHAWK, must follow these steps,

1. Connect OLED to I2C port of Pixhawk

2. Upload ardupilot firmware, at least 3.5 version, below 3.5 version will not be display.

3. Use Mission Planner to modify parameters NTF_DISPLAY_TYPE to 1. After modify, remember to click “Write Params” button.

4. Now the OLED is only supported for ardupilot firmware,can not be supported PX4 firmware

5. Reboot the board.

MINI OSD MAVLink OSD Board

Features:

• 100% brand new and high quality

• Perfect combination of ATmega328 and MAX7456.

• Flight Control OSD functions

• Supports MAVLink protocol.

• Uses MAVLink OSD.

• Supports pirate APM and PIXHAWK Flight Control

• Specifications:

• Material:plastic,Metal

• Item Name: MINI OSD MAVLink OSD Board

• Operating voltage: 5V-12V

• Application:DIY Flight Control Projects

Package Content:

• 1 x MINI OSD Module

By default, we had uploaded the firmware and charset for MINI OSD, you can use it directly.No need to upload firmware for MINI OSD.
