Product Description
8 Ports DMX/ArtNet/SACN Model NO.: AD-8 Features:
1.Supports 8 ArtNet universes, total 8X512 channels.
2. Double network port supports Serial connection, which can control 32768 uni-verses,a total of 16777216 channels
3. Ethernet l/0 based on high speed switch, without signal delay.4.supported protocols: Art-Net/ sACN/ DMX 512
5. lt allows to configure parameters and update sofware version through computer6. Used for extending the DMX output all DMX Console with Artnet or sCAN,such asTiger,MA.
7. You can choose "Hold "or "Black",When there is no signal at the DMX8. DMX ports:3pins XLR (Option: 5 pins XLR ).
9. Support electrical isolation between all in/outputs: 1 port out of work does notinfluence the other ports.
10. LED indicators for each input and output.
11. Adopt MeanWell wide input power supply to ensure a stable electricity supply
Technical parameters:
Network signal : ARTNET/TCP IP/ sACN
Number of signal channels: 8 DMX512 outputs and inputs
Operating voltage AC 100V ~ 240V 47/60 HZ
Product Dimensions (LxWxH): 483 x 175 x 44 mm
Net weight: 2.4 KG
Functional features:
1. Independent research and development of software is by no means a copy
2. The CPU uses advanced ARM Cortex-m4
3. Each channel of output signal is independently photoelectric isolated, and the isolated power supply is 2000V DC
4. Console that supports all ART NET network protocols, such as Pearl Expert, Touch Tiger, MA, Fliggy, etc.
5. Conventional DMX512 signals can be converted into ART NET network signals.
6. Device firmware can be upgraded through USB flash drive or network
7. System parameters can be set through LCD screen or network.
8. Aluminum alloy brushed housing, standard 1U 19-inch rack mount
