Product Description
Edge AI Computer AI Box with NVIDIA Jetson AGX Orin Module with GMSL 32GB 200TOPS 64GB 275TOPS reComputer Robotics J5011 J5012
Edge AI Computer AI Box with NVIDIA Jetson AGX Orin Module with GMSL 32GB 200TOPS 64GB 275TOPS reComputer Robotics J5011 J5012reComputer Robotics J5011 is a power edge box with NVIDIA Jetson AGX Orin™ 32GB module. It features rich IOs, such as USB, Ethernet, CAN, RS-232/422/485, DI/DO and GMSL. It also features connectivity M.2 Key E slot for Wi-Fi/BT and M.2 Key B slot for 4G/5G modules, making it perfect candidate to be the brain of sophisticated mobile robots or autonomous vehicles.Feature
Powerful embodied AI PlatformCompatible with the Jetson AGX Orin32GBmodule,offeringcomputing capability of200TOPS. Perfect platform for embodied AIandAMR
Multi-ConnectivityFeaturing2xM.2KeyMslotsforSSD,M.2KeyEslotforWi-FiandM.2KeyBslotfor4G/5G
Wide Voltage Input RangeCan be used in 48V battery power system
Rich IO capabilitiesIncludes most common IOs used in roboticsandAMRprototyping, such as USB, 10G Ethernet,CAN, RS-232/422/485,I2C,SPIandI2S
Vision AI SupportFeatures 4x 4-lane CSI output, and can be connected up to 8x GMSL2 cameras, making it ideal for vision AI applications such as BEV, Occupancy Grid, SLAM etc
SpecificationProduct | reComputerRoboticsJ5011with GMSL Extension | |
Storage | 2x M.2 Key Mslot(1x128GSSDincluded) | |
Networking | 1x M.2 Key E slot for WiFi/Bluetooth module 1x M.2 Key B slot for 4G/5G module | |
I/O | USB | 3x USB 3.0Type-A (5Gbps); 1x USB 3.0 Type-C (Recovery); 1x USB 2.0 Type-C (Debug); |
RJ45 | 4x 1G Ethernet 1x 10G Ethernet | |
GMSL | 8x GMSL2 (MAX96712 as deserializer) | |
CAN | 4x CAN （CAN-FD supported) | |
Serial | 2x RS-232/422/485 | |
DI/DO | 4x DI 4x DO | |
IO | 1xSPI1xI2C1xI2S | |
Display | 1x HDMI 2.1 | |
Fan | 1x 4-pin Fan Connector (12V PWM) | |
Button | 1x Reset Button; 1x Recovery Button | |
RTC | 1x RTC 2-pin1xRTCsocket | |
Power | DC19V~48VTerminalBlock2-pin | |
Mechanical | Dimensions (W x D x H) | 210mm*180mm*87mm (with stands) |
Weight | 2.95 kg | |
Installation | Desk, wall-mounting | |
Operating Temperature | -10℃~60℃ | |
Warranty | 2 Year |
Compatible GMSL Cameras supported in Jetpack
Manufactuer | Model | Resolution |
Sensing | SG3S-ISC031C-GMSL2F | 1920H*1536V |
SG2-AR0233C-5200-G2A | 1920H*1080V | |
SG2-IMX390C-5200-G2A | 1920H*1080V | |
SG8S-AR0820C-5300-G2A | 3840H*2160V | |
Orbbec | Orbbec Gemini 335Lg | 3D |
Autonomous mobile robot
AI Robot Development
With AGX Orin module, this most powerful embedded AI system lets you create advanced robotics and edge AI applications for manufacturing, logistics, and healthcare. It’s the most powerful embedded system, pushing the limits of AI robotics. The Isaac robotics platform offers NVIDIA-accelerated systems, libraries, and generative AI models to enhance AI perception, manipulation, and simulation in robotics.
Learn about Issac platform
Isaac - AI Robot Development Platform | NVIDIA Developer
Multi-Sensor Fusion for Autonomous Mapping & Navigation
reComputerRoboticsJ501 supports sensor-rich autonomy by integrating data from LiDAR (via Ethernet/CAN), 3D cameras (via USB/CSI), GPS, and IMU (via UART). Using AI models and algorithms like ORB-SLAM,A-LOAM,NVBloxor Nav2, it performs sensor fusion, real-time localization, path planning, and obstacle avoidance. The low-latency processing on theAGXOrinSoC allows autonomous systems to adapt to changing terrain or obstacles on the fly. Its wide voltage input and compact form factor make it suitable for mobile deployment, enabling robust, edge-level autonomy without external compute.
Designed for demanding AI applications：
Such as AMR, smart retail, industrial automation, and video surveillance, smart video analysis scenario
The NVIDIA Isaac™ platformdelivers the NVIDIA® CUDA®-accelerated libraries, application frameworks, and AI models you need to create autonomous mobile robots (AMRs), arms and manipulators, humanoids, and more.
reComputerRoboticsJ501 | x1 |
AGXOrin32GB/64GB | x1 |
128GBSSD | x1 |
Terminalblockto DC power cable | x1 |
USB Type-C to Type-A cable | x1 |
PanelMount | x2 |
DINRail | x1 |
