LT3045 module 5v single power supply module two parallel connected low noise linear RF power supply voltage buck
LT3045 module 5v single power supply module two parallel connected low noise linear RF power supply voltage buckKW_3045-2 module shipping listModule + PDF data + two XH2.54-4P power cords + after-sale technical support + electrostatic bag packaging + shockproof foamTips:(1) The module interface of our store is clear and the performance is stable. Please perform functional verification under the corresponding experimental conditions in conjunction with the product details of our store.(2) The basic parameters of this module are in the details page. Schematic diagrams and engineering documents are not provided. Please be clear to the buyer. If you have any operation problems, please contact customer service.(3) Buyers, before using the module, please read the details page of this module to understand the power supply and use restrictions, to avoid damage to the module due to improper operation.(4) Our modules are guaranteed to provide real module parameters, functions and pictures, and all modules will be shipped after detection.Module parametersModule model: KW_3045-2; dual LT3045Module type: linear regulator buckInput voltage: +20V(MAX)Output voltage: 4 versions; +5V, +9V, +12V, +15VOutput current: dual 500Ma (MAX)Input and output pressure difference: <500mVOutput power: dual 6W (12V/0.5A) for reference onlyLoad adjustment rate: ±0.5%Voltage adjustment rate: ±1%Static power consumption: 6mASwitching frequency: none; linear power supply does not have this parameterOutput ripple: better than 1mV; no loadModule noise: 0.8µVRMS (10Hz-100kHz)Module PSRR: 76dB at 1MHzModule protection: none; no reverse connection protection, no fuseModule features: multiple; dual output, users can connect in parallel to increase output current; ultra-low noise, ultra-low ripple; with input power indicatorModule applications: multiple; precision operational amplifiers, high-speed/high-precision data converters, RF circuit power supply, etc.Module weight: 45g; with radiatorModule size: 50*30*24.5; length*width*height (mm) (with radiator)Module heating: the greater the load, the greater the heatingWorking temperature: -40—+85℃Module interface: XH2.54-4PModule descriptionKW_3045-2 is developed by ADI's LT3045 high-performance low-dropout linear regulator chip, which can provide designers with a complete solution for high-precision power supply simulation applications. This LDO has ultra-high PSRR performance and extremely low output noise. It is designed for noise-sensitive applications (eg, PLL, VCO, mixer, low noise amplifier (LNA), power amplifier (PA), precision operational amplifier, ADC, DAC and other high-performance analog circuits).
Precautions for using the module(1) The module has no reverse connection and overvoltage protection, please buyers carefully check and compare the power supply and then power on, otherwise it will damage the module.(2) The heating of the linear power supply is mainly determined by the output voltage difference and the load current. Please choose and use the power supply module reasonably. Generally, you need to reserve 30% of the vacancy.(3) The module belongs to the step-down type module, the input voltage needs to be greater than the output 1V or more to stabilize the output.(4) The module generates heat during use, please purchasers to enhance heat dissipation according to the actual situation. When carrying a large load, the heat sink can be appropriately increased.(5) When using the module, it is recommended to add 100uF or larger electrolytic capacitors to the input and output terminals.(6) It is recommended to use our transformer and rectifier filter module, which can be used as a precision power supply.Frequently asked questionsQ: Can the module power the audio equipment?A: This power module is a high-quality power module, designed for powering RF equipment and high-end audio equipment.Q: Can the two outputs of the module be connected in parallel?A: When the two output voltages are the same, you can connect the two outputs in parallel. At this time, the maximum output current is 1000mA. It is not recommended to use the maximum current, and a certain margin is required.Q: Why can't I test the nominal ripple parameters? The measurement ripple is relatively large.A: First of all, you need to have the correct measurement method. You can search for the power supply ripple measurement method. There are many explanations. Secondly, the linear power supply can only suppress the ripple noise of the input signal, but it is not infinite. If you use a switching power supply input and the noise is large, the linear power supply will not play a big role, so the general linear power input is through the transformer Rectifying and filtering. This shop has a full set of transformer rectification and filtering linear power supply solutions and modules.About Prime Living
