8K 60HZ HDMI-Compatible Converter HDMI2.1 Audio Extractor With 7.1CH/5.1/2.0 Coa

Product Description

If you like our products please you add to cart or add to Favorites,Surprise coupons is waiting for you to extract,
more refined small gifts free to send, please contact customer service.
If you follow our store and become our fans, you can get extra 5% discount for some designated products.

8K 60Hz HDMI Audio Extractor 7.1CH 5.1CH 2CH Stereo Audio Extractor Converter Optical TOSLINK SPDIF Audio Splitter Adapter

Description:

ZY-8V1,Navceker 4K 120Hz HDMI 2.1 Audio Extractor is a high performance 1 HDMI input and 1 HDMI output with HDMI audio out .HDMI AUDIO ONLY /Toslink/Coaxial/3.5mm jack audio output support audio extract function ,The system supports all 3D TV formats in addition to all HDTV formats up to 8K@60Hz,4Kx2K@120Hz RGB 4 :4 :4 .

Features:

HDMI 2.1 Audio Extractor Converter 4K 120Hz HDMI 2.1 Audio Converter 8K HDMI to HDMI Audio+Video+Digital Coaxial Audio+Aux Audio

Excellent Quality

• 【8K HDMI Audio Extractor】Navceker 8K HDMI Audio Extractor is designed for high-performance audio extraction. It features 1 HDMI input and 1 HDMI output with audio extraction functionality. The audio can be output through a 3.5mm Audio Jack, Toslink SPDIF, Coaxial, and HDMI Audio Port. This allows users to utilize their existing audio receiver to receive audio from 8K@60Hz, and HDCP 2.3 content. This product supports HDMI loop-out and 10-bit HDR (High Dynamic Range) for enhanced visual quality.

• 【High Resolution】The HDMI audio extractor converter supports HDMI resolutions up to 8K@60Hz, 4K@120Hz YUV 4:4:4, and 2K@144Hz. It also supports Dynamic HDR, HDR10+, VRR, Chroma 4:2:0/4:2:2/4:4:4, Dolby Vision, HDCP 2.3, and variable refresh rate technologies such as AMD FreeSync and G-Sync. This brings you an incredible visual experience and faithfully restores the intended visual effects.

• 【HDMI Audio Extractor Formats】HDMI Audio Formats: PCM 2.0, LPCM 5.1/7.1, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS 5.1, DTS ES 6.1, DTS HRA, DTS HD Master, DTS: X. It supports Blu-ray 24/50/60fps/HD-DVD/XVYCC. SPDIF/Coaxial Formats: LPCM 2.0/5.1, Dolby Digital 2.0/5.1, DTS 2.0/5.1.

• 【Wide Compatibility】The HDMI audio splitter supports HDCP 2.3 and is compatible with HDMI 2.0b. HDMI input supports devices such as computers, laptops, PS3, PS4, Xbox, Blu-ray DVD players, STBs, and more. HDMI video output supports projectors, HDTVs, screens, monitors, and similar devices. HDMI audio output supports home theaters. Optical SPDIF and Coaxial output support speakers. 3.5mm jack output supports headphones.

• 【Four Audio EDID Settings】The 4 audio modes allow you to choose the desired audio format for output. These modes include TV Mode, 2.0CH Mode, 5.1CH Mode, and 7.1CH Mode. The HDMI audio extractor comes with a remote control, which makes it easy to switch between these audio modes.

PACKAGE:

• 5V/1A DC Power Adapter...............................1 pcs

• User Manual........................................................1 pcs

• IR Remote control..............................................1 pcs(without battery)

• 48Gbps HDMI 2.1 Audio Extractor.......................1 pcs

SPECIFICATIONS

Input ports..............................................................................1XHDMI

Output port........................................................... 1 XHDMI(Female type )

1 XHDMI Audio output...........................support 7.1CH audio extract function

1 XToslink Audio output........................support 5.1CH audio extract function

1 XCoaxial Audio output........................support 5.1CH audio extract function

1 x3.5mmJack output .............................support 2.0CH audio extract function

Audio support.....................LPCM 7 .1CH,Dolby TrueHD ,DTS-X and DTS -HD Master Audio

Video Resolution........................................up to 8k@60Hz/4K@120Hz RGB 4 :4:4

Operating Temperature...................................0 C to 40 C/ 32Fto 104F

Storage Temperature.......................................- 20 C to 6 C/ -4F to 104F

Dimensions...........................................................130X61X30MM

CONNECTION DIAGRAM

Notes :

1 .Navceker HDMI 2.1 audio extractor not support ARC or eARC function

2 .When you use 7.1CH mode,if your TV/monitor not support 7.1CH audio,there are be no audio signal.

3.when you want to get 7.1CH audio,please you set audio out of your HDMI 2.1 source(PS5/XBox etc) with auto mode or source mode or 7.1CH mode.

4.Not support eARC or ARC soundbar,such as ARC, e-ARC/Sonos ARC soundbar etc
