Official Din Base with 500mAh Battery

Product Description

DinBase is a "5X5cm" series base specially designed for "DinRail" rail fixing. It is suitable for M5Core, and built-in 500mAh lithium battery, can be externally input DC power supply (support 9~24V). On-board power physical switch to completely shut down external power and battery. Reserved Port B and Port C interfaces. Lego mounting holes on the lower side for easy fixing, and the bottom supports standard 35mmDinrails. In addition, 4 plug-in ears are provided to support a variety of fixing methods. DinBase has a number of proto pads reserved on the internal PCB for easy DIY.

Features

*1X12P 2.54 interface
*Port B, Port C interface
*Power supply mode:
--DC power supply (9-24V)
--500mAh lithium battery
*Power switch
*Multiple mounting options:
--DinRail
--hanging ears
--two copper nuts embedded in the bottom
--three LEGO fixing holes on the sides

Include

1*DinBase
4*Hanger
1*Snap
1*Hex key
2*nut(2×25mm for Core2/CoreS3)
2*nut(2×22mm for Core1)
2*nut(2×20mm for Core2/CoreS3)

Applications

1.DIY
2.Scenarios where hosts such as M5Core are powered separately
