8-Encoder Unit (STM32F030)

Product Description

UNIT 8Encoder is a set of 8 rotary encoders as one of the input unit, the internal use of STM32 single-chip microcomputer as the acquisition and communication processor, and the host computer using I2C communication interface, each rotary encoder corresponds to 1 RGB LED light, encoder in addition to left and right rotation, but also radially pressed, in addition to a physical toggle switch and its corresponding RGB LED light, including 5V->3V3 DCDC circuit. The unit can be used for the input of multi-channel relative control values, the corresponding RGB lamp can display different statuses, and the toggle switch can be used for the input of multi-channel switching quantities. It can be used as a multi-degree-of-freedom robot or music equalization application.

Features

8-channel Rotary encoder
8 channels correspond to RGB lights
I2C communication
Toggle switches can be used for multi-channel switching inputs
Radial press function
HY2.0-4P interface
2x LEGO compatible holes

Includes

1x 8Encoder Unit
1x HY2.0-4P Cable(20cm)

Applications

Multi-degree-of-freedom robot joint control
Music equalization control aspects
Multi-channel light control
